Infiray Gemini GEH50R
Binocular multispectral device in the high-end range
Objective Lens: 50 mm
Thermal Sensor Resolution: 640x512 px
Pitch: 12 µm
NETD: ≤ 25 mK
Field of view (HxW): 8.8°x6.6° (15.4x11.5 m at 100 m)
Magnification: 4.1x (optical); 1x, 2x, 3x, 4x (digital)
Maximum Detection Range: 2,600 m (object size 1.7x0.5 m)
Night Vision Imaging:
Objective Lens: 35 mm
Digital Night Vision Sensor Resolution (CMOS): 1,920x1,080 px
Pitch: 4 µm
External IR Illuminator: 940 nm
Field of View (HxW): 9.4°x7.0° (16.4x12.2 m at 100 m)
Magnification: 3.8x (optical); 1x, 2x, 3x , 4x (digital)
Display: 2x AMOLED 1,024x768 px
Eye Relief Diameter: 7 mm
Eye Relief: 15 mm
Pupillary Range: 61 to 72 mm
Diopter Compensation: ± 5 dpt
Laser Rangefinder: 1,200 m, measuring accuracy ±1 m from 3 to 100 m and ± (1 m + measuring distance × 0.25%) above 100 m
Power Supply: 2x18650 Li-Ion battery / 3.2 Ah / 3.7 V
Operating Time: Up to 6 h
Dimensions: 198x154x78 mm
Weight: 960 g approx.
The Infiray Gemini GEH50R is the world's first multispectral binoculars with advanced thermal imaging technology, an HD day vision function and an integrated laser rangefinder
Presented with the Gemini GEH50R Infiray a new, multispectral optical thermal imaging binocular that combines the advantages of the latest thermal imaging and night vision technology with an integrated laser rangefinder and HD daylight function. The high-resolution thermal image sensor with 640 x 512 pixels, 12 micron pitch and a thermal sensitivity of less than 25 mk NETD is combined with a focusable color tag sensor that delivers razor-sharp images.
The Gemini GEH50R is perfect for game viewing, hunting, stalking and security purposes. The specially developed ergonomic shape of the GEH50R offers a high level of comfort and ease of use even during longer periods, allowing seamless switching between day, night and thermal vision or a fusion of image modes for the ultimate detection capability!
Stunning focusable observation during the day
Thanks to the focusable 4 μm color full HD daytime sensor, the Gemini can be used like binoculars, whether day or night. Day and Night modes offer 3,8x to 15,2x optical magnification, providing a real advantage when viewing wildlife even at long distances.
